Type 505 Double Acting - Sizing
Sizing - Double Acting Actuators
The suggested safety factor for double acting actuators under normal working conditions is 20% - 30%.
Example:
• The torque needed by valve = 100 Nm.
• The torque considered safety factor (1 + 30%) = 130 Nm.
• Air supply = 5 bar.
According to the output torque table on double acting actuators the smallest model we can choose is Model 105.
Actuator
size
Air Supply Pressure
Nm at 6 bar
ISO 5211 / mm Product no.
BV Dimensions BV Torque
Nm ISO 5211 / mm
40
9.2
F04 / 9
F04 / 11
50500
40
449
50500
40
441
52
23.9
F04 / 11
F03-F05 / 11
50500
52
441
50500
52
351
DN 50
DN 65
10.0
16.2
F05 / 11
63
43.8
F05-F07 / 14
50500
63
574
DN 80
DN 100
23.7
35.0
F05 / 11
F05 - F07 / 14
75
60.2
F05-F07 / 14
50500
75
574
DN 125
58.7
F07 / 14
83
94.1
F05-F07 / 17
50500
83
577
DN 150
83.7
F07 / 17
92
135.4
F05-F07 / 22
50500
92
572
105
198.4
F07-F10 / 22
5050
105
702
DN 200
163.7
F10 / 22
125
301.0
F07-F10 / 22
5050
125
702
DN 250
280.0
F10 / 22
140
513.0
F10-F12 / 27
5050
140
028
DN 300
401.2
F10-F12 / 27
160
798.0
F10-F12 / 27
5050
160
028
DN 350
770.0
F12-F14 / 27
190
1276.0
F14 / 27
5050
190
888
DN 400
1093.7
F12-F14 / 27
210
1596.0
F14 / 36
5050
210
883
DN 450
1496.2
F14-F16 / 36
240
2308.5
F16 / 46
5050
240
665
DN 500
1987.5
F14-F16 / 46
270
3508.9
F16 / 46
5050
270
665
DN 600
3263.7
F16-F25 / 46
Sizing - Double Acting Actuators for Butterfly Valves
The torque for the butterfly valves are with a safety factor of 25%. Please remember that the actuator torque is based on an air supply of 6 bar at
the actuator position.
