B-V-NOTCH-UK-02-2014 REV. C
3-PCS BALL VALVE - FOR V-NOTCH BALL
0 20
-20
-40
40 60 80 100 120 140 160 180 200 220 240 260
10
20
30
40
50
60
70
80
Bar
Temperature in [°C]
90
100
110
120
130
-28° WCB
-38° AISI316
DN 08 - DN32
DN 40 - DN65
PRESSURE/TEMPERATURE (SEATS PTFE+25%C)
L
H
H1
B2
B1
B4
B3
E
D
C
K
L2
ISO 5211
F
M x 4
(G)
ød
ød
øG
øG
FB
RB
TYPE 1210 / 1310
Dimension
Valve with handle
Iso top flange
Stem
[mm]
L [mm]
L2
B2
øC
E
H
H1
ISO
5211
G
K
Mx4
B3
øD
F
B1
B4
Thread BW SMS [mm]
[mm]
[mm]
[mm]
[mm]
[mm]
[mm]
[mm]
[mm]
[mm]
[mm]
[mm]
[mm]
[mm]
DN08FB
64,8 64,8 64,8 24.5 29,8
10
134 64,3 37,2 F03
36
25
M5
0,5
9,5
6,5
7,4
6,1
DN10FB / DN15RB
64.8 64.8 64.8 24.5 29.8
10
134 64.3 37.2 F03
36
25
M5
0.5
9.5
6.5
7.4
6.1
DN15FB / DN20RB
72.5 75.0 75.0 24.5 29.0
15
134 71.5 45.1 F03
36
25
M5
2.0
9.5
6.5
16.1
7.3
DN20FB / DN25RB
85.4 89.8 89.8 31.4 33.0
20
134 76.0 51.1 F03
36
25
M5
2.0
9.5
6.5
18.1
8.8
DN25FB / DN32RB
105.3 109.4 109.4 41.3 36.0
25
170 82.3 60.6 F04
42
30
M5
2.0
11.1
8.0
24.6 11.0
DN32FB / DN40RB
111.0 114.4 114.4 48.4 40.0
32
170 87.3 64.3 F04
42
30
M5
2.0
11.1
8.0
24.3
9.7
DN40FB / DN50RB
127.3 130.0 130.0 56.3 47.3
38
207 103.6 77.5 F05
50
35
M6
2.0
14.3
9.7
30.2 12.2
DN50FB / DN 65RB
145.0 145.0 145.0 71.4 69.5
50
207 121.6 95.0 F05
50
35
M6
2.0
14.3
9.7
30.2 12.2
Dimension
*) Torque
Weight
Butt weld ends
[mm]
[inch]
FB [Nm]
RB [Nm]
FB [kg]
RB [kg]
Type 1210
Type 1310
SMS3008
øG x mm (ød)
øG x mm (ød)
øG x mm (ød)
DN08
1/4”
9.6
-
0.80
-
13.7 x 3.2 (7.3)
13.5 x 1.6 (10.3)
10.0 x 1.0 (8.0)
DN10
3/8”
9.6
9.6
0.80
0.66
17.5 x 3.2 (11.1)
17.2 x 1.6 (14.0)
12.0 x 1.0 (10.0)
DN15
1/2”
10.8
9.6
0.82
0.66
21.3 x 3.2 (14.9)
21.3 x 1.6 (18.1)
18.0 x 1.0 (16.0)
DN20
3/4”
14.4
10.8
1.28
0.87
26.9 x 3.2 (20.5)
26.9 x 1.6 (23.7)
25.0 x 1.2 (22.6)
DN25
1”
19.2
14.4
2.07
1.36
33.7 x 4.0 (25.7)
33.7 x 2.0 (29.7)
32.0 x 1.2 (29.6)
DN32
1 1/4”
31.2
19.2
2.65
2.01
42.4 x 4.0 (34.4)
42.4 x 2.0 (38.4)
33.7 x 1.2 (31.3)
DN40
1 1/2”
40.8
31.2
3.79
2.69
48.3 x 4.0 (40.3)
48.3 x 2.0 (44.3)
38.0 x 1.2 (35.6)
DN50
2”
57.6
40.8
5.51
4.04
60.3 x 4.5 (51.3)
60.3 x 2.0 (56.3)
51.0 x 1.2 (48.6)
DN65
2 1/2”
-
57.6
-
6.78
76.1 x 4.5 (67.1)
76.1 x 2.6 (70.9)
63.5 x 1.6 (60.3)
MANUEL CONTROL VALVE
DVC has developed a convenient and simple economi-
cal manual operation control valve. The solutions are
suitable for process applications that don´t demand
dynamic adjustment.
DVC lockable lever are made from AISI304 stainless
steel. Scale is 0-100% open, mounted on top of the
valves ISO top. Position can be fixed by bolt/nut.
DVC lockable levers are available for TYPE 1210/1310
and TYPE 1211/1311. Others on request.
30
o
60
o
90
o
